Product Description
This 57BL Brushless DC Planetary Gear Motor with Driver Kit offers a powerful and efficient solution for robotics, automation, and precision mechanical systems. Designed for use with a 24 V DC supply, it delivers approximately 800 RPM no-load speed and consistent performance under load. The brushless motor provides lower noise, longer life, and reduced maintenance compared to brushed designs.
The integrated planetary gearbox ensures smooth torque delivery and compact mechanical packaging, while the included driver module makes integration into control systems fast and convenient. The driver supports speed adjustment, thermal protection, over-current protection, under-voltage protection, and reversible rotation for enhanced control and safety.
This motor is suitable for use in a variety of applications requiring reliable high-speed motion and long operating life.
Specifications
Motor Specifications
-
Motor Type: Brushless DC planetary gear motor
-
Rated Voltage: 24 V DC
-
Phase: 3
-
Poles: 4
-
Gear Ratio: 4.25
-
No-Load Speed: ~800 RPM
-
Rated Speed: ~705 RPM
-
Rated Torque: 0.76 N·m
-
Construction: Planetary gearbox with compact footprint
Driver Specifications
-
Included driver module allows direct speed adjustment via built-in potentiometer
-
Reversible motor rotation control
-
Protection functions: over-heat, over-current, under-voltage
Physical Dimensions
-
Motor Diameter: 57 mm
-
Motor Length: ~73.8 mm
-
Gearbox Diameter: 56 mm
-
Gearbox Length: ~41.3 mm
-
Output Shaft Diameter: 12 mm
-
Output Shaft Length: ~30 mm
Applications
This brushless planetary gear motor with driver kit is ideal for:
-
Robotics motion systems
-
Automated conveyor and positioning equipment
-
Precision drives in automation
-
Mobile robotics platforms
-
Actuation systems requiring controlled speed and torque
-
Embedded machinery requiring integrated driver support
What’s Included
-
1 × 57BL Brushless DC Planetary Gear Motor (24 V, ~800 RPM)
-
1 × Matching Driver Kit with adjustable speed and protection
