Description:
The RS555-EN 24V DC Motor with Encoder is a high-performance 36D brush motor designed for applications requiring high speed, precise control, and reliable torque. Equipped with a 2-channel Hall effect encoder (17 PPR), this motor ensures accurate feedback for intelligent systems, making it ideal for robotics, smart vehicles, and automated machinery.
Featuring an internal cooling blade, the motor achieves balanced heat dissipation, maintaining stable power output even under prolonged use. Its robust construction delivers high torque with a rated torque of 0.8 Kg·cm and a stall torque of 3 Kg·cm, while offering a long operational lifetime exceeding 1000 hours.
This compact yet powerful 36D motor spins at a no-load speed of 16,000 RPM, and under rated conditions, runs at 10,000 RPM with a 6.5A rated current. Its 3mm x 22mm shaft is compatible with various gear reducers and mechanical assemblies.
Applications:
-
Intelligent self-balancing two-wheelers
-
Autonomous tracking cars
-
Smart home appliances
-
Robots and robotic arms
-
Camera gimbals and rockers
-
Gear reducer systems
Motor Dimensions: 36D x 57L
Shaft Dimensions: 3D x 22L
Specifications:
-
Model: RS555-EN 24V
-
No-load speed: 16,000 RPM
-
No-load current: 0.5A
-
Rated speed: 10,000 RPM
-
Rated torque: 0.8 Kg·cm
-
Rated current: 6.5A
-
Stall torque: 3 Kg·cm
-
Stall current: 37A
-
Encoder: 2-channel Hall sensor, 17 PPR
-
Built-in cooling blade for heat dissipation
-
High torque, stable performance, long life
