Description
The 45JX100K Series DC Planetary Gear Motor is a compact high-torque brushed gearmotor designed for robotics, automation equipment, AGV drive systems, smart machinery, conveyor systems, and DIY motion control applications.
Powered by a 24V DC 795 motor and paired with a full-metal planetary gearbox, this motor delivers stable output torque, low-speed operation, reversible rotation, and adjustable speed control compatibility. Multiple reduction ratios are available, ranging from high-speed 3240RPM configurations to ultra-low-speed 3RPM high-torque versions.
Its 45mm gearbox diameter, 10mm keyed shaft, and robust planetary reduction structure make it suitable for robotic wheel drive systems, industrial automation, small electric vehicles, intelligent equipment, and heavy-load transmission projects.
Features
- 24V DC brushed planetary gear motor
- High torque full-metal planetary gearbox
- Reversible CW/CCW rotation
- Supports PWM speed control
- Multiple gear ratios and output speeds available
- Compact 45mm gearbox design
- 10mm keyed output shaft
- Stable low-speed high-torque operation
- Suitable for robotics and automation applications
Applications
- AGV / AMR robots
- Robotic wheel drive systems
- Conveyor systems
- Industrial automation
- Smart machinery
- DIY robotics projects
- Electric tools
- Motion control equipment
- Automated gates and actuators
Specifications
| Item | Specification |
|---|---|
| Product Type | DC Planetary Gear Motor |
| Motor Model | 795-24120 |
| Gearbox Model | 45JX100K |
| Rated Voltage | 24V DC |
| Motor Power | 40W |
| Motor Type | Brushed DC Motor |
| Gearbox Type | Planetary Gearbox |
| Gear Material | Full Metal |
| Rotation Direction | CW / CCW Reversible |
| Speed Control | Supported |
| Gearbox Diameter | 45mm |
| Motor Diameter | 43.2mm |
| Output Shaft Diameter | 10mm |
| Shaft Type | Keyed Shaft |
| Shaft Length | 20mm |
| Mounting Holes | 4 × M4 |
| Ambient Humidity | 20%–85% RH |
| Operating Temperature | -20°C to +65°C |
Motor Technical Parameters
Dimensions
Package Includes
- 1 × 45JX100K DC Planetary Gear Motor
