Product Description
Upgrade your automation robotics and smart equipment with the DC Worm Gear Motor 5840 31ZY designed for high torque smooth operation and long service life
This model features a durable metal worm gearbox M8 threaded 25mm output shaft and supports forward and reverse rotation
Worm gear structure provides self locking capability the shaft will not rotate when power is off making it ideal for applications requiring secure positioning and safety
The 5840 31ZY worm gear motor delivers reliable power under continuous load supports both 12V and 24V input and is widely used in household appliances medical devices commercial machines and robotic systems
Key Features
✔ Metal Worm Gearbox high strength long lifespan
✔ High Torque Output for lifting pushing rotating and positioning
✔ Self locking design no back drive when powered off
✔ Smooth and quiet operation
✔ M8 threaded 25mm output shaft easy to connect directly to mechanisms
✔ Supports CW CCW rotation
✔ Compact size with strong load capacity
✔ Perfect for continuous duty applications
Specifications Table
| Parameter | Value |
|---|---|
| Model | 5840 31ZY Worm Gear Motor |
| Gearbox Type | Metal Worm Gear |
| Output Shaft | M8 Threaded Shaft |
| Shaft Length | 25 mm |
| Rated Voltage | 12V 24V |
| Rotation | CW CCW |
| Structure | Self locking no reverse drive |
| Unit Weight | 355 g |
| Packaging Quantity | 56 pcs per ctn |
| Carton Size | 38.5 27.5 24 cm |
| Gross Weight | 20.8 kg per ctn |
| Net Weight | 19.9 kg per ctn |
Applications
This motor is suitable for high torque precision control and long term reliability
Household Appliances
-
Electric curtains
-
Integrated stoves
-
Coffee machines
-
Smart toilets
-
Dishwashers
-
Sweeping robots
-
Range hoods
-
Smart door locks
Personal Care
-
Curling irons
-
Massage devices
-
Electric clippers
Office Equipment
-
Shredders
-
Printers
-
Projectors
-
Banknote counters
-
Coin counters
Medical Equipment
-
Massage chairs
-
Electric carts
-
Medical pumps
-
Electric beds
-
Electric wheelchairs
Industrial and Automation
-
Water and electric valves
-
Air switches
-
Pumps
-
Automatic door systems
-
Lubrication equipment
Commercial Equipment
-
Vending machines
-
Parking locks
-
ATM machines
-
Smart lamps
Robotics
-
Manipulators
-
Drones
-
Service robots
-
Autonomous platforms
Why Choose This Worm Gear Motor
-
Excellent torque and holding force
-
High efficiency metal gears
-
Reliable continuous duty operation
-
Perfect for motion control and positioning
-
Ideal for automation and robotic builders
